XPS Spectra
Cobalt (Co) Compounds
The XPS Spectra section provides raw and processed survey spectra, chemical state spectra, BE values, FWHM values, and overlays of key spectra.
Atom% values from surveys are based on sample, as received, and Scofield cross-sections. Atom% values are corrected for IMFP and PE.
Peak-fits are guides for practical, real-world applications. Peak-fits are not fully optimized or designed to test any theory.
Cobalt metal (Coo)
Survey, Peak-fits, BEs, FWHMs, and Peak Labels
| → Periodic Table | → Six (6) BE Tables |
| Survey Spectrum from Coo Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag (3d5/2) FWHM = 1.3 eV |
|
  |
|
| → Periodic Table | → Six (6) BE Tables |
| Co (2p) Spectrum from Coo – Raw Fresh exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
Co (2p3/2) Spectrum from Coo – Peak-Fit Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
 |
 |
| Co (2p) Spectrum from Coo– Extended Range Fresh exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
Co (2p) Spectrum from Coo– Expanded Vertically Fresh exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
 |
 |
|
|
|
| → Periodic Table | → Six (6) BE Tables |
| O (1s) Spectrum from Coo – Raw Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
O (1s) Spectrum from Coo – Peak-Fit Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
 |
 |
|
|
|
| → Periodic Table | → Six (6) BE Tables |
| C (1s) Spectrum from Coo – Raw Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
C (1s) Spectrum from Coo – Peak-Fit Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
 |
 |
| → Periodic Table | → Six (6) BE Tables |
| Co (3p) Spectrum from Coo – Raw Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
Co (3p) Spectrum from Coo– Peak-Fit Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
 |
 |
|
|
|
| → Periodic Table | → Six (6) BE Tables |
| Co (3s) Spectrum from Coo – Raw Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
Co (3s) Spectrum from Coo – Peak-Fit Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
 |
 |
|
|
|
| → Periodic Table | → Six (6) BE Tables |
| Auger Signals from Coo – Raw Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
Valence Band Signals from Coo – Raw Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
 |
 |
|
|
|
| Overlays |
|
| → Periodic Table | → Six (6) BE Tables |
| Valence Band Spectra – Overlay of Coo and CoO Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
Co (2p) Spectra – Overlay of Coo and CoO Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
 |
 |
| Co (3s) Spectra – Overlay of Coo and CoO Freshly exposed bulk, Flood gun is OFF, C (1s) BE = 283.5 eV, Ag FWHM = 0.75 eV |
|
 |
|
|
End-of-spectra-page Price to purchase raw data sets: Transmission Function Tests |
|
| December 2015 – Transmission Function of Thermo K-Alpha Plus |
| → Periodic Table |
| Survey Spectra of Ion Etched Copper (Cu), PEs = 50, 100, 150 and 200 eV |
 |
|
|
| → Periodic Table |
| March 2016 – Transmission Function of Thermo K-Alpha Plus |
| Survey Spectra of Ion Etched Copper (Cu), PEs = 100, 150 and 200 eV |
 |
|
|
| → Periodic Table |
| August 2019 – Transmission Function of Thermo K-Alpha Plus |
| Survey Spectra of HOPG (C), PEs = 20, 50, 100 and 200 eV |
 |
|
|
| → Periodic Table |
| January 2022 – Transmission Function of Thermo K-Alpha Plus |
| Survey Spectra of Ion Etched Copper (Cu), PEs = 100, 120, 140, 160, 180 and 200 eV |
 |
